Fire Sprinkler Hose and Connection Set/DN20 (FM Appr)
| Hose Type | Standard Corrugated Metal Hose | |||
| Hose Dimension | DN20 ( 3/4'') | |||
| Hose Material | Stainless Steel AISI316L | |||
| Union Material | Carbon Steel | |||
| Cover | Non-Covered | |||
| Connection Type | Male-Female | |||
| Design Pressure | PN16 | |||
| CODE | SIZE | QUANTITY IN BOX | ||
| DN (mm) | CONNECTION (Inch) | LENGTH (L) | ||
| TF401 | DN 12 | 1/2''-1/2'' | 500 MM | - |
| TF402 | DN 12 | 1/2''-1/2'' | 700 MM | - |
| TF403 | DN 12 | 1/2''-1/2'' | 1000 MM | - |
| TF404 | DN 12 | 1/2''-1/2'' | 1200 MM | - |
| TF405 | DN 12 | 1/2''-1/2'' | 1500 MM | - |
| TF406 | DN 12 | 1/2''-1/2'' | 2000 MM | - |
